UNI-CUT Automatic Nut Tapping Machines
UNI-CUT
Single Spindle Reversible Automatic Nut Tapping Machine
Fully automatic tapping of nuts with a blind hole, as well as through-hole threads. The central feature of this machine is its reversible working spindle. All kinds of union and cap nuts, round and weld nuts, as well as all types of turned and special parts can be machined. The low-cost machine is mechanically controlled. All movements are monitored by a PLC.
| Machine | Uni-Cut 10 | Uni-Cut 20 |
|---|---|---|
| Thread dimension | M3 – M12x1,5 1/4” – 1/2”-16 | M5 – M20x1,5 3/16” – 3/4”-16 |
| Max. outside diameter of parts | 25 mm | 50 mm |
| Max. length of parts | 70 mm | 70 mm |
| Power of spindle motor | 1,1 kW | 2,2 kW |
| Speed range | 700 – 2800 rpm | 400 – 2000 rpm |
| Max. Output | 4500 pcs/h | 3500 pcs/h |
| Steering of the machine | mechanisch / SPS | mechanisch / SPS |
| Necessary air pressure | 4 bar | 4 bar |
